SUB-GASKET™ Nacelle Gaskets

Product Overview

SUB-GASKET™ Nacelle Gaskets are utilised to prevent cold welding between offshore wind farm turbine / nacelle and vessel stillage during mobilisation and transportation to the offshore wind farm installation and construction location.

Product Images


  • Sub Gasket
  • Sub Gasket
  • Sub Gasket
  • Sub Gasket
  • Sub Gasket
  • Sub Gasket
  • Sub Gasket
TECHNICAL SPECIFICATIONS
Description Specification
Turbine / Nacelle Model V112 - 3.0 MW (MHI Vestas Offshore Wind)
Turbine / Nacelle Weight (Static) 2 Mpa / 157 Te
Max. Contact Pressure (Dynamic) 35 Mpa / 35 N/mm2 / 5,075 psi / 350 bar
Min. Contact Pressure (Dynamic) 22 Mpa / 22 N/mm2 / 3,191 psi / 220 bar
Temperature - 10 oC to + 35 oC
Gasket Utilization >2
Gasket OD 3,184 mm
Gasket ID 3,018 mm
Gasket Thk 5 mm
Gasket Width 83 mm
Gasket Circumference 10,003 mm
Gasket Hole Specification 24-off / Ø 36 mm / 3,100 mm PCD
Gasket Material Subthane™ High Compression
Features
  • 4-piece design / 4-off quadrants
  • Compression & abrasion resistant
  • Rapid preparation & installation
Clients & Track Record
Ref. Clients Specification
P-218 E.ON Kårehamn Nacelle Gaskets SES Installation Onboard MPI Discovery 08-off SUB-GASKETTM Nacelle Gaskets
P-414 E.ON Humber Gateway Nacelle Gaskets SES Installation Onboard MPI Discovery 08-off SUB-GASKETTM Nacelle Gaskets
